| X96mini (S905W) | ||||||||
| CPU | Amlogic S905W Quad Core ARM Cortex A53 @2GHz | |||||||
| GPU | Penta-core Mali-450MP GPU @ 750MHz, | |||||||
| Memory | DDR3：1GB (Option: 2GB) | |||||||
| Flash | eMMC：8GB (Option:16GB ) | |||||||
| WiFi | IEEE 802.11 b/g/n | |||||||
| Moudle | Plastic : Black Color | |||||||
| I/O | 1*HDMI | 4K*2K UHD Output, HDMI 2.0A | ||||||
| 1*AV OUT | 480i/576i standard definition output | |||||||
| 2*USB | 1* USB Host Port ,1*USB Device | |||||||
| 1*IR Reciver | Remote Reciver Connect | |||||||
| 1*RJ45 | Ethernet Interface | |||||||
| 1*TF CARD | Support 4GB/8GB/16GB/32GB/64GB | |||||||
| Power | DC 5V/2A；LED indicator，Working ：Blue; Standby：Red | |||||||
